Announcement: The Offical 2nd Hooters Meet. |
- |
EMC 3000gt |
6787 |
--
Last post by: EMC 3000gt
|
| Important Topics |
 |
 |
|
12
|
bobthecow |
7,675 |
21st May 2009 - 03:01 AM Last post by: bobthecow |
I will post pics of my installation in the near future. Hopefully this will clear up any misunderstandings with audio installation, or equipment.
Car Audio FAQ
Hello all, and welcome to my car audio FAQ. I will try to answer every question that I can in a semi-brief fashion. I have been doing car audio installations for about 5 years now, and know a great deal about the profession.
I. How to plan your audio system
II. What brands to go with
III. How do you want it to look
IV. Installation Techniques
V. Disclaimer
Section I, planning your audio system
To plan your audio system, you must first think about what you want out of it. Do you want to keep it simple with just an aftermarket head unit, maybe you want to add new speakers as well. Then there is the possibility of getting a little more advanced and adding amplifiers and subwoofers, tweeters and component speakers, and for those of you with amps over 500 watts, a capacitor.
The second thing that you have to do is set priorities on the items that you want to get. An aftermarket head unit is the best thing to start with. It will make your stock speakers sound clearer, as well as give them a bit more power. Next would be new speakers, followed by an amp and subs. After doing all of this, you may want to think about amping up all of your speakers.
Third and finally you need to find out how much you are willing to spend on this audio system. A mediocre system without subs will cost about 300-500 USD. A good quality system with subs will cost anywhere from 600-1000 USD. High quality will cost you about 1100-2000 USD. Finally an excellent sound system with component speakers, amps, subs, and a high quality head unit can cost up to about 5000 USD. I have never done a competition system for anyone, but I have heard they can get up to about 10000 USD.
To show you the expenses you might be getting into here is what I have done to mine:
Head Unit: Blaupunkt Key West MP36
Speakers: Blaupunkt Velocity Series, full range speakers all the way around
Soon To Be Added Speaker Amp: Eclipse EA4000
Subs: 2 Infinty Reference 1040w
Sub Amp: Audiobahn 8002v
Capacitor: Rockford Fosgate 1 farad capacitor
My entire system cost a bit over 2000 dollars with my box, wiring kits, materials, and the likes.
Section II, What brands to go with, or to stay away from
Here are the two best websites for car audio:
www.crutchfield.com
www.sonicelectronix.com
Some brands are good for certain aspects of audio, while being poor at others. An example of this is Eclipse. Their amps and head units are some of the best, but their speakers and subs aren’t that great. Hopefully this list will help you decide. Keep in mind, con doesn’t mean that the item sucks, it just means that it isn’t as good as some others.
There are certain brands that you should stay away from no matter what. These brands are: Sony, Emerson, Jensen, Boss, Bose, Visonik, Directed Audio, Soundstream, Bazooka, Fusion, Lightning Audio, Phoenix Digital(not to be confused with Phoenix Gold), Precision Audio, Treo, Profile, and Extreme Audio. All of these companies suck for car audio, trust me. The bolded items are those that are spoken highly of, but are of poor quality, both in sound and craftsmanship.
There are brands that have no flaws in my opinion: Clarion, Focal, Infinity, JL Audio, Boston Acoustics, Memphis, Phoenix Gold, Kenwood eXcelon, Pioneer Premier, Pyramid, Rockford Fosgate Power Series. The items in bold are brands that I push heavily.
My opinion on everyone’s favorite, Kicker. Kicker makes all of their products seem larger than life, and better than anything else on the market. Here is my “beef” with them. First and foremost, Kicker makes a square subwoofer, and they claim that it produces better sound. The problem with this claim is that sound waves are round, not square. Second, they claim everything to be “comp.”, which is another lie, because even their top of the line stuff cannot be seen at competitions actually winning any prizes. And lastly, they just flat out aren’t worth the cost. Infinity costs about the same and it is at least twice as good.
Alpine Pros: Speakers, Subs, Head Units
Alpine Cons: Amps
Audiobahn Pros: Amplifiers, Head Units
Audiobahn Cons: Speakers, Subs
Blaupunkt Pros: Speakers, Subs, Head units
Blaupunkt Cons: Amps
Dual Pros: Amps
Dual Cons: Head units, speakers, subs
Eclipse Pros: Amps, head units
Eclipse Cons: speakers, subs
JBL Pros: Speakers, Subs
JBL Cons: Amps, Head units
Kenwood Pros: Amps, Subs, Speakers
Kenwood Cons: Head Units
MTX Pros: Subs, Amps
MTX Cons: speakers
Pioneer Pros: Head Units, speakers, subs
Pioneer Cons: Amplifiers
Rockford Fosgate Punch Series Pros: Amps
Rockford Fosgate Punch Series Cons: Speakers, Subs, Head Units
Section III, How do you want it to look
Do you want your audio system to function properly, or do you want it to function properly and look good, or do you want it do be like a professional job? Are you looking to make things permanent, or do you change your mind frequently? These kinds of questions are what I ask the people who come to me to install stuff for them. A decent job that is done right, but not very professionally takes me about an hour. A professional job can take me anywhere from eight to 12 hours for me to do. I charge by the job, not by the hour, so time is not a factor for me. However, it may be for you. If you don’t feel like spending all day, or all weekend doing this, then you can do it the quick and easy way.
The quick and easy way: wire crimp connectors, wire caps, duct tape, the sorts of everyday items. The wiring looks like a mess, you can visibly see it in some places, and all and all it just looks like crap.
The semi-professional job: Electricians tape. The wires are hidden, but the locations for them aren’t good , I.E behind the pedals of your car. The items are screwed into place, no dynamat is used, and the connections could still be better.
Professional Job: Heat Shrink, solder, caulk, the works. Dynamat is used in every single panel, everything is seated perfectly or fabricated to do so. You not only screw the speakers in, but also you caulk them. Wires are first soldered, and then heat shrink is applied to make them look perfect. No wires are showing anywhere except right near the component hook ups, aftermarket grills are used, and no shortcuts are taken… well kinda.
Section IV, installation techniques
Some people make the mistake of wiring things wrong because the don’t have a harness, others have problems keeping their speakers from rattling, and still others drill thousands of holes into their firewalls trying to get that amp wire through. Well this is the section for those people. With my experience in car audio, I will help you to make your installation look as professional as possible. I do not have the time or resources to do vehicle specific installations for you, but if you PM I will try my best to help. This is meant for a really basic, professional looking installation. It will cover a CD Player, non component Speakers, Subs, a single Amp, and a Capacitor.
For Head Unit installations: My Recommendation, Pioneer Premier
First thing is first, when you buy your head unit from wherever, make sure you get a wiring harness specific to your vehicle and a mounting kit specific to your vehicle. Now then, go to your local hardware store and pick up a heat gun(a blow dryer on steroids). I believe that Sears and Home Depot have relatively cheap heat guns. While you are there pick up a material called heat shrink, you will need 20-16 gauge. You also will need a soldering gun and some solder, it is easiest to solder with a silver exterior, acid core.
Take your new head unit out of the box, and inspect it for any shipping damages. If you have a removable faceplate, I suggest you utilize it until you have the installation complete. The wiring harness you purchased should have a sheet with it, or say on the packaging what wires do what function. Your new head unit will have a plug of it’s own that goes into the back of it. Your new head unit should have marked on it somewhere(if not look in the owners/installation manual), what the wires for it’s plug mean as well. Write down the connections on a piece of paper, as to not forget, solder is nearly permanent. KEEP THE CHART YOU MAKE UNTIL YOU ARE DONE WITH EVERYTHING
Go home and get used to soldering on some extra speaker wire that you may have laying around. Try to make it very neat, go very slowly, but then again you must work quickly, once it cools down, there is no turning back.
Now then, once you have done that, you can start the actual connection process. Get all of the wires ready by stripping about half an inch to an inch off of their covers Place of piece heat shrink over the open end of the wire(on either harness), and let it slide all the way down to the bottom of the harness. Twist the two wires together, try to keep them in a semi-straight line, or the heat shrink wont fit properly when it comes time to actually shrink it. After you have twisted the wires together, very neatly solder them. The connection is very strong with solder, so you shouldn’t ever have to worry about it breaking. After you have soldered your wire, slide the heat shrink tube over the solder connection and use your heat gun to shrink it up. If you did it correctly, it will look very professional. Stand back and admire your work, and then realize that you have about 10-15 more of these things to do.
After you have finished linking the head unit to the wiring harness that you bought, you can plug it in to your car, attach the antenna, RCA cables and remote wires for amps, and last but not least, your ground wire. You have now finished your head unit… hooray. Now on to speakers.
Speaker Installation: My Recommendation, Blaupunkt Velocity for the speakers, Rockford for the wiring
Speakers are the easiest thing to do, but can be extremely frustrating at times. On my 1991 and 2002 Eclipses you have to pull of damn near every interior panel to get to the speakers. Every vehicle has a different way to get to the speakers, and as stated before, I won’t spend the time doing vehicle specific installations on this site. To make your speakers look like they have been professionally done, you must be very careful with your interior panels. Mitsubishi makes them thin, and they crack very, VERY, easily.
You will need to go to the hardware store and pick up some silicone caulk, then to the car audio store and pick up some speaker wire, preferably 16 or 18 gauge wire. You will also need your soldering gun/solder, and your heat gun/heat shrink.
The first thing you will need to do is look at your chart that you made for your head unit and figure out which wire is the plus and which wire is the minus on each speaker. Then, as I said earlier, very carefully undo all the panels needed to get to your speakers. Once your stock speaker is exposed, take it out, cut the old wires as close to the plug as possible, and strip the casings off of them.
To get your new speaker ready, you first will need cut about a six inch new section, then strip some of your new speaker wire, half an inch to and inch on both ends should be fine. Now, solder the connection to the wires running from your head unit, to the new speaker wires. Slide a piece of heat shrink over the open end and use your heat gun to tighten it up. Solder your wire to your speaker, and then caulk the edge of the speaker, making sure that you don’t cover up the screw holes. Push it down in it’s original opening, and finally, screw the speaker back into place. The caulk will make an airtight seal that will keep the speaker from popping, which will make it sound better. It also will provide a little more sound dampening, and will help to keep the speaker in place if a screw comes loose.
Subwoofer Installation: My Recommendation, JL Audio W7 subs, Rockford wiring
Subwoofers are easy as pie. Since they aren’t already in your car, you cant remove them, and you have one less thing to do. You need to decide what size subs to get. The size of the subs is based on what type of music you most often listen to. 8’s are good for rock, extremely poor for rap. 10’s excel with rock, and poor with rap. 12’s are decent for rock, and really good for rap. 15’s are horrible for rock, and excellent for rap.
You will need to go get some 12 or 14 gauge speaker wire for this job. You also will need the solder, heat shrink, and caulk again. You will need a box. Here is a list of box types and what they are good for:
(10’s and smaller) Sealed- best for tight, responsive bass. Good for punk rock, emotional, classical, classic rock, and old metal
(10’s and 12’s) Ported/vented- best for continuous bass, a little louder but poorer sound quality. Good for new metal, industrial, death metal, rock, techno, and the likes.
(10’s and larger) Band pass- best for continuous obnoxiously loud bass, extremely poor sound quality. Good for rap, that’s about it.
To install your new subs into their box you must do the same thing you did for speakers. You need to solder, heat shrink, and caulk them into place. Okay, you are done with that now.
Amplifier Installation: My Recommendation, Audiobahn Amp, Rockford wiring (like $150, ouch)
Your amplifier should supply no less than 50% of the max RMS of your subs. It should supply no more than 90% of the max RMS of your subs. Amps need to be placed in a Wiring kits need to be bought according to size of the amp:
<500 watts- 8 gauge
500 to 1000 watts- 4 gauge
1000 to 1500 watts- 2 gauge
1500 or more- 0 gauge
You will need wiring terminals for whichever size wire you have. Your local audio store should have them. The best materials are gold plated or platinum plated. You will need a pair of pliers to crimp the wire terminals to the wires, or if you are a weaker individual, you might need a hammer to do the same.
Okay, whichever side of your car the battery is on is the side that you will need to run your amp power wire and remote turn on wire. The opposite side is for your RCA cables. Do the RCA first, it is the easiest part. Just run it under your door-sill panels, next to the carpeting. It should tuck away quite nicely between the plastic and the carpet. Run it like this all the way back to the amplifier.
Now for your remote wire, run it the same way, but on the opposite side of the car, if it is going to run on the drivers side, make sure that you tuck it beneath the carpeting behind your pedals, if not, you may break the wire, or cause an accident.
Now for the power wire, which is the one that everybody always does wrong. DO NOT UNDER ANY CIRCUMSTANCES, DRILL THROUGH YOUR FIREWALL. Okay, now then, to the correct way. The side of your car that the battery is on, the same side you ran your remote wire for, is the side you will run for your power cable. Take off the plastic inside of your wheel-well, and you should see a bunch of holes going into your engine bay. Those are the holes that you will run the wire through. Take the non-fuse side of your wire, and run it down from the engine to the wheel well, via the holes that are there. Once you have ran the wire through the hole, you can proceed to pull it through, make sure you leave enough slack for your fuse side to connect to the battery. Open the door on the appropriate side of the car, you should see a black rubber hose running from your doorframe, into the car. Get a screwdriver and poke a hole from the inside of the vehicle to the outside. Attach the power wire to the screwdriver with some electrical tape and pull it into the cabin. Now, hide the wire underneath the paneling in the same fashion that you did the remote wire.
Finally, you can connect it all up. Plug in all the RCA, remote, and speaker wires in the back first, then the ground, and finally the power wire. After the back wires are in, you can plug the power wire into the battery.
And you are finished.
Section V Disclaimer
I am not responsible for any damage to your vehicle. Although I have been doing this for years, it is possible that I missed something. If you have any questions, or run into any problems with your car audio installation, feel free to pm me.
This guide is the sole property of me, C. Nicholas Ambs (aka,bobthecow). Any use or posting of this guide without my express written consent is prohibited. Good luck, and happy installing.
 |
 |
|
7
|
vintagepostcards |
2,375 |
23rd April 2009 - 03:44 PM Last post by: ckid222 |
Anyone can get their radio code for free direct from Mitsubishi by telephone. You will need the following information:
Last 8 characters of your VIN #
Radio Serial Number
Call Mitsubishi:
1-888-mitsu20 (1-888-648-7820), option 1, option 4
Current hours: 6am to 5pm Pacific, M-F.
Tell representative that you replaced your battery and now need your radio code. If you are not currently a registered owner, they will ask for your info for registration.
How to find your Radio Serial Number
It is located on a label on the radio. You will need to remove the dashboard panel covering the radio. For my Mitsubish Eclipse, it was easy (might be same for other vehicles):
Remove the two screws located underneath the radio. Just go to the edges of the radio and follow it down going underneath the dash. You will need a small philips head as there isn't much clearance especially on the left side. You can then pull away the plastic exposing the radio itself. The plastic panel just tugs straight out from the dash. Pull out the bottom first. Then tug the top straight out, to pull it away from the snaps holding it on.
The Mistubishi representative asked me for the Radio Serial Number only, not the Radio Manufacturer's Number (MR...). The serial number was visible for me without removing the radio itself (unscrewing it from the dash). However, you might want to leave the panel off until you get your radio code in case they ask you for the MR # and you have to unscrew the radio from the dash to see that part of the label.
How to enter your Radio Code
(Courtesy of mittech)
Use the first four radio station preset buttons to enter the code.
1: Push radio preset#1 until first digit of your code appears.
2: Push radio preset#2 until second digit of your code appears.
3: Push radio preset#3 until third digit of your code appears.
4: Push radio preset#4 until fourth digit of your code appears.
5: Push either tape or cd button.
What to do if your radio says OFF instead of CODE
(Courtesy of mittech)
If your radio says OFF it means you entered the wrong radio code three times. To get it to say CODE again do the following.
1:Turn the key to on or accessory.
2:Push the power button so that the radio display says OFF.
3:Let the car sit for 1 hour.
4:The radio display will go blank.
5:Turn the radio on and it will say CODE again.
 |
 |
|
17
|
mittech |
9,777 |
5th October 2008 - 05:20 PM Last post by: dinan3 |
If your radio says "Off" it means you entered the wrong audio code three times. To get it to say code again do the following.
1:Turn the key to on or accessory.
2:Push the power button so that the radio display says off.
3:Let the car sit for 1 hour.
4:The radio display will go blank.
5:Turn the radio on and it will say code again.
 |
 |
|
43
|
dylanjacobus |
32,660 |
29th May 2008 - 10:22 PM Last post by: SgtSharpie |
Alright I am sure someone here can help me out. I am trying to install my aftermarket stereo into my 2001 Eclipse with the Infinity system. I got the wiring harness from crutchfield and the install kit. But when I connect all the wires, the cp player turns on and there is no sound from any of the speakers.
I noticed that there is a whole lot of connections on the stock cd player and only an fm antenna and the dinky little harness for the aftermarket one. So my question is, do I need to get more adapters, or what?
| Forum Topics |
 |
 |
|
0
|
vtwin0162 |
2 |
Yesterday, 12:41 PM Last post by: vtwin0162 |
Just bought car
Noticed that the A/C Cpmpressor Connecter was gone
I got the connecter but the compressor side has 4 wires
The engine side only hase 3 wires(pink-orange & Blk/wht)
Wiring diagram shows there should be a black/red wire
HELP!!!!
 |
|
|
0
|
Aiden J |
4 |
Yesterday, 10:31 AM Last post by: Aiden J |
i bought an aftermarket gauge face plate and tried to hook it up but for some reason it doesn't seem to want to light up at all. i'm wondering if anyone has any idea where i am supposed to hook the positive and negative wires up to so that is works with my original dimmer switch.
this is of course on a 93 Honda Prelude, but pretty much all dimmer switches in all the cars are the same if not extremely similar. any help will be great thanks.
 |
|
|
2
|
annlor2 |
184 |
8th March 2010 - 02:12 PM Last post by: bumpn |
I need the code for98 mitsubishi galant vin no 4a3aj56g7weO27255 serial no of radio 7210a656a
 |
|
|
0
|
new_old_montero |
7 |
3rd March 2010 - 04:38 PM Last post by: new_old_montero |
The bass/midrange speaker in the front driver's side door of my 01 Montero Sport is starting to develop a buzz and I need to replace it. It has a component speaker system with a bass/midrange speaker in the lower part of the door and separate tweeter at the top of the door. I can not find specs for the audio system in this vehicle anywhere. I'm hoping that someone here can tell me what type of speaker is in the lower part of the front doors. Store websites tell me that a 6.5 inch speaker will fit, but they don't tell me whether I need to get just a woofer or something like a 3-way speaker. I don't want to miss or duplicate any part of the frequency range if I can help it. It's been close to 20 years since I've replaced a speaker in a car, so any help you can offer is greatly appreciated.

 |
 |
|
1
|
tbruno1 |
21 |
1st March 2010 - 06:18 PM Last post by: Aiden J |
Hey everyone,
I'm not particularly car savvy, yet. But, I learn quickly. Anyways, I'm about to install a new receiver in my 2003 Galant, and I have the wiring harness and a 6 pin DIN adapter on the way. I was looking at pictures of it, and the end has 4 RCA plugs and then another wire coming out of it. Now, I assume, since there are only 2 RCA inputs in the back, I just pick two and plug them in, but I don't have any idea what to do with the extra wire.
Advice?
Thanks for your help!
-Travis
 |
|
|
1
|
Davefyil |
27 |
1st March 2010 - 06:13 PM Last post by: Aiden J |
I would like to ask a few questions in regards to this project.
Can I run the lights and switches right off of the battery ?
Does anyone have a link to a reference diagram of how to hook up LED lighrs under the car ?
Any and all advice is appreciated
 |
|
|
4
|
chain rattle |
43 |
28th February 2010 - 08:44 PM Last post by: jesse hammant |
what current groups /bands play good doof doof music
a youtube link would be good
 |
|
|
3
|
ricanevo |
271 |
27th February 2010 - 09:09 AM Last post by: ramikaze |
Hello in need of some help.
I bought a 07 outlander MMCS navigation system for a 08 evo x that I was told powers up in Japanese. My question is, is there a language menu on the navi and if so can someone please write up a how to change the language to ENGLISH from Japanese please?
also if anyone knows where I can get the navigation install kit so i can add the navi to the evo x GSR SSS?
Thanks a million for the help.
 |
|
|
0
|
Joao82 |
12 |
22nd February 2010 - 09:15 PM Last post by: Joao82 |
Hey Guys,
Just wanted to inform everyone that I'm in the final stages of my proposal so I can present to a hand of manufacturers.
I am not selling anything.
But I do require your assistance in showing some interest on this item, so I can include it in my proposal.
If you can please give me some support by saying YES TO DOUBLE DIN KIT.
I do appreciate everyones effort and lets hope to see this kit in production very soon.
For people not aware of the Double Din kit, it was AKA the Orbital Kit. I pretty much bought all the rights, patents, certificates and technical docs. The only difference is I want to make this kit available to all at a affordable price, which unfortunatelly Orbital did not.
http://features.evolutionm.net/article.php?id=73Thus, my need for support from all you loyal Lancer/Evo enthusiasts , so that I may have a strong enticing proposal.
Thanks again for your time in reading and ofcourse your support

 |
|
|
0
|
Joao82 |
41 |
3rd February 2010 - 09:53 PM Last post by: Joao82 |
Hey Guys,
I have outstanding News. I have an opportunitty to make this kit available. This kit will allow you to install a DOUBLE DIN radio in your Mitsu. Lancer 2002-2007. This kit is not available anywhere else. This kit will make your 2002-07 Lancer look like a 2009 EVO. I'm in the initial steps of gathering funds to make it into to production to be more affordable to the end user.
I would appreciate if there is any interest for this DD kit for you to just PM me and SAY, "
Yes to DD kit for Lancer 02-07"
That would be greatly appreciated and help me have this DD kit available in the very near future.
Check link below and read all about the quality of the DD kit...
http://features.evolutionm.net/article.php?id=73
 |
 |
|
0
|
Jeffrey83 |
44 |
3rd February 2010 - 09:56 AM Last post by: Jeffrey83 |
First of all, hi guys,
Got my black '08 Lancer 1.8 CVT Instyle not too long ago and I'm absolutely in love with it! Really something different than my old '96 Eclipse turbo

The Instyle model is European only I think, but anyway it's the most complete one (with leather, mmcs, spoilerpackage, rearview cam, etc, etc)
Anyway, I have some weird problem with the MMCS voice control phone system. Or well, I assume it's in the MMCS but I'm not sure if the non-mmcs cars have the same way of calling.
I have my phone paired, went without problems. When I start the car and I want to call, I press the button at the steering wheel. The system starts, the voice tells me "xperia connected" (as that is my phone) "ready"
Then no matter what I say, it will 90% of the time do something weird...
No matter if I say call, dial, setup or cancel, it will randomly do something like "dialing 08" "dialing *" "dialing 78" (the 8 seems to happen often). Even if I don't say a thing and just press the hang-up button, it won't do it and starts to dial something. Sometimes it also asks me if I want to change the language to french or german :s It's all quite random, doesn't make any sense AT ALL.
So when it starts to dial something, I start pressing the hangup button a few times until it goes back to audio mode.
The weird thing is this: when I do this AGAIN (without turning the engine off) , it will work flawless without any problem. I just press the call button again, give the voice command about what I want to do, and it never failed on this point. So to me this indicates that the voice recognition and phone connection are just fine.
I tried to do the voice recognition thing a few times, without any noticable sounds from outside the car, but it keeps doing this.
I also went to the dealer, but like I said before, it's failing 90% of the time and of course, when I was there it was in the 10% of the time it actually worked...
So before I go back to the dealer again, I'd like to know if anybody else has this same issue or not, and maybe if somebody has a solution.
About the software in the system... I'm not very sure about software versions but I do know that my navigation maps are from 2007.
Any help or clues or information is appreciated.
 |
|
|
493
|
07mitsueclipse |
44,174 |
2nd February 2010 - 06:06 PM Last post by: 07mitsueclipse |
Hello,
I thought I might be able to help out here. If you are in need of a Radio Code please feel free to reply to me and I can help you out with the issue. All i need from you is the actual Serial Number from the radio itself and the part number, this way im able to help you get this code.
 |
 |
|
0
|
sailormannen |
14 |
23rd January 2010 - 07:26 AM Last post by: sailormannen |
Hi all!
I'm been searching whole Internet now for this matter. In all languages, all shops, Mitsubishi sites, forums in all languages I really cant find it anywhere. I'm surprised its never been taken up.
Well I'm not at my car for some weeks so I can't just go out and measure them. But I would really want to order new ones while I'm away because the old one is broken now.
As I said its a Mirsubishi Carisma Elagance 1.8 GDI -00 I think they made the same model of Carisma -99 to -04 so its probably the same speakers in all of those.
I would like to have the size of all the speakers, the 2 in the frontdoor (I think this ones is 5 1/4") , the 2 in the frontdoor at the backmirror (think this is 1") and the 2 rear speakers (witch I have no clue of the size).
So anyone with this kind of car, can't you do a check up on your car for the size, or if you just know it, pls tell me.
Kindliest regards from me.
Ciao!
 |
|
|
0
|
Cletus |
16 |
20th January 2010 - 09:45 AM Last post by: Cletus |
You think we would one day be able to see a
Mitsubishi TV this size in the trunk of a car?
 |
|
|
0
|
murphyoutlander |
21 |
18th January 2010 - 03:29 PM Last post by: murphyoutlander |
Hi,
Can anyone tell me where/if I can get European maps for my North American Outlander? I brought my Outlander with me from Canada when I moved to Germany, and don't have any maps. I've checked with a dealer in Germany and they said the format the European maps come in are not compatable with the North American dvd/navi system. My dealer in Canada has no access to European maps. Is there a way around this?
Thanks
 |
|
|
42
|
mitsubishiwontdo |
20,093 |
18th January 2010 - 05:59 AM Last post by: Zauersuvis |
My radio model# MR252914, Serial# 66218043. My ole lady sure would appreciate it.
 |
|
|
1
|
yeogav |
16 |
13th January 2010 - 07:22 PM Last post by: yeogav |
Hi peeps,
Just wondered if anybody can help?
I have bought a Grandis Warrior with a Rosen G8 dvd player for the passengers entertainment (roof mounted)
The Wireless headphones work a treat but when I select speakers I cannot get any sound out through the speaker system. The manual says it should also display the radio frequency on the dvd screen when I select speakers ON. It doesnt so I am not even sure if it is transmitting on the FMM. I have tried all frequencies on the car radio but dies not pick up any signal from the dvd player.
Am I doing something wrong? Any help would be appretiated!!
cheers
 |
|
|
0
|
CDNinKS |
15 |
6th January 2010 - 06:40 PM Last post by: CDNinKS |
In Thailand the new (2009) Pajero Sport GT comes with an Alpine stereo and a separate 7" touch screen that is NAVI capable. They are offering an Alpine GPS portable unit with a docking cable to feed into the 7" screen, but very expensive at $1000 CDN. Can anyone tell me if this screen is in fact an Alpine screen? Is it possible to get a Garmin remote GPS receiver that will feed into this unit?
Any help would be appreciated.
 |
|
|
0
|
Mutabot |
17 |
21st December 2009 - 06:00 PM Last post by: Mutabot |
Hello,
Did anyone by any chance came across plain white/gray backlit head unit?
Looks like my stock radio does not support AUX, and I'm looking for replacement that looks decent, without all that christmacy lights that most of current stereos have...
Thanks,
Michael
 |
|
|
0
|
Mutabot |
23 |
21st December 2009 - 05:46 PM Last post by: Mutabot |
Hi All!
Is there a way to somehow enable aux line-in in MITSUBISHI U068 (MR490089) head unit?
There is a 13-pin din connector at the back, and I assume there would be a cable that connects to there and provides line-in, but my searches in this direction are fruitless. The best I could find is some Mitsubishi-MB adapter for 100$ in Russia, that looks overpriced for the task.
Did anybody came across the same problem?
Thanks!
Michael
 |
|
|
0
|
jbrunclair |
35 |
10th December 2009 - 01:38 PM Last post by: jbrunclair |
hello,
i'm looking for the map disc for mitsubishi carisma.... constructor seems to be navteq...
since i changed the car battery, i can't change radio frequence neither listen to an audio disc until i insert the map disc to reinstall the system software... :(
thanks for help...
jerome.
 |
|
|
0
|
dezel29 |
37 |
2nd December 2009 - 09:09 PM Last post by: dezel29 |
hey guys/girls...i just got my car...have a few questions about some stuff behind the dash...thanks
aftermarket kenwood receiver...i have 2 seperate antenae wires ...why ? lol
my dimmer switch doesnt work...any solutions ?
i found 2 boxes under the dash...one is marked MICRO and is blue...the other is a black box with mitsubishi on it...both have antenaae wires coming off them...i dont have remote to anything and i dont see any flashing leds on my dash...any suggestions ?
thanks







 |
|
|
0
|
charli3isbor3d |
89 |
18th November 2009 - 10:57 AM Last post by: charli3isbor3d |
first off, i have a 2002 lancer ls, and i just finished hooking my woofers up, all is good but the fact that i have no way of hooking my ipod up(atleast not that i know of) My headunit has no aux in, just aux outs, and i cant plug my ipod directly into into it via the 3.5 mm, because there isnt one, and all the fm transmitters have sucked? any other way to do it, or should i just get a new head unit? any information would be helpful
-thanks
 |
|
|
0
|
4nak1n |
45 |
13th November 2009 - 11:45 AM Last post by: 4nak1n |
Hi, i got a magna sport 1999 with a factory fitted FM tuner. Now i just bought another factory cd player from mitsubishi. I don't want to throw away my old fm radio so i leave it there. But i recognized there is only one cable (with a white big head) and one blue cable (with a circle head). I have to unplug it from the old to to fit into the cd player in order to get it working. Now the fm radio was like some sort of decorate thing.
Now i want to have another pair of the big white one and the blue one to make the fm tuner working. Can anybody help me?
Is there something in the market that convert 1 to 2 plug from one original cable sort like that (it's like in the electronic stuff)?
 |
|
|
4
|
mfalik |
1,165 |
8th November 2009 - 03:13 AM Last post by: Brade |
Hey everyone. My attempts to install an Infinity Sound System from a 04 Ralliart, in my ES have come to a hault.
I'm trying to find the 18-pin, white connector that connects to the amp. Right now my only option is to purchase the entire instrument panel wiring harness for $880, like that's going to happen.
So if anyone out there has a source, or has the stock Infinity Sound System and is looking to upgrade their stereo with aftermarket components. Please let me know.
Thanks for your help.
Mike
mfalik@hotmail.com
 |
|
|
0
|
WadeKidder |
62 |
5th November 2009 - 05:57 PM Last post by: WadeKidder |
 |
|
|
60
|
wrwaustralia |
7,024 |
25th October 2009 - 05:59 AM Last post by: jonny_bravo18 |
Hi Guys,
I have the Factory Workshop Manuals for the 2008 Mitsubishi Lancer.
Volume 3 has full Audio Wiring Diagrams, Systems Operations, Fault Finding and Specific Testing Procedures.
Each speaker has it's own diagnostic test which can be run from the Head Unit Display.
If you own a 2008 Lancer, I'm happy to email the PDF File (20.6 Mb) which will cover all Chasiss Electrical.
Warren
Melbourne, Australia
 |
|
|
0
|
dealrocker |
35 |
23rd October 2009 - 06:56 AM Last post by: dealrocker |
Yesterday I was at BestBuy and found a Griffin Technology - iTrip Auto FM transmitter for iPod & iPhone. After going through some reviews and research, this FM Transmitter certainly seems like a great device to me. Before any purchase decision I want to know your advice from your personal experience.
Thanks..
 |
|
|
2
|
Starsky |
42 |
7th October 2009 - 01:54 AM Last post by: Boydee |
Hello all,
I have a lame problem with my car, the upper beams are not working, but the lower beams + position lamps are working without problems.
Until now i thought "who cares" but the other day i almost crashed with a moose while driving at night so LOL, i thought it'd be the time to fix that damn thing.
Issues: Upper beams not working (blue indicator on dashboard doesnt turn on) + button to wash headlights not working either
Tried as far as now: Checked fuses, Relays, Changed the switch (the one on the steering wheel - damn mitsubishi got me to change it even if that was not the problem!) and of course, even checked the bulbs themselve.
I even went to the car dealer and after they got me to change the switch they have no idea where the problem is, and im not willing to pay them for wasting a lot of time on thinking about the solution for a problem they dont even know how to fix :'(
Please help!
 |
|
|
0
|
Uli |
195 |
5th October 2009 - 08:20 PM Last post by: Uli |
Can someone help me get the radio code?
I called the local dealer and they wanted 46 bucks.
 |
|
|
1
|
simonngo |
731 |
27th September 2009 - 11:17 PM Last post by: chollinger |
Can any one give me any instruction and what tools I need to remove strock stereo from 2006 lancer es
 |
|
|
0
|
boazs |
65 |
12th September 2009 - 02:15 PM Last post by: boazs |
Hi all.
I got my eclipse spyder 2008 imported to israel, but the radio zone does not match here.
can someone tell me how can i change the radio tuner zone to the europian method?
thanks,
boaz
 |
|
|
0
|
Sultan9 |
81 |
10th September 2009 - 11:18 AM Last post by: Sultan9 |
 |
|
|
1
|
Webby Carl |
50 |
30th August 2009 - 06:27 PM Last post by: Webby Carl |
G'day,
My pajero was stolen several years ago.
Nowdays, I use a GPS tracking device along with my car alram.
What would you suggest using, to further protect my car.
Obviously, I have car insurace. I was thinking about Ravelco(www.ravelco.com)? heard good things about them.
What about a leech device or a starter disabler?
 |
|
|
1
|
Shanis33 |
228 |
25th August 2009 - 05:27 AM Last post by: krd |
Hi All
I Have just bought a 2008 pajero with the MMCS in it i was wondering if anyone knows how to bypass the speed sensor or has a wiring diagram for the fosgate mmcs in it .
 |
 |
|
0
|
Dhaval Patel |
60 |
13th August 2009 - 01:06 PM Last post by: Dhaval Patel |
Hi Guys,
My name is Dhaval Patel, I am brand new user of this forum
I drive Mitsubishi Lancer 2003
Actually I am stuck with my Audio system in my car
I took of old one, ordered new Kanwood system with AUX, and open all wires, cut the wires from old socket and everything. Now when i was trying to match the wire colors with wiring diagram which i got from internet, It is not matching a single wire.
Kanwood says they can't take my system back because it is limited timing of 15 days trial
I spend 89 bucks for new system and i don't know how to install this.
Not only that, since when i cut down all wires from old socket, My Headlights, Auto lock, inside light, Emergency parking light everything is not working when the ignition is OFF, If i make it on everything works.
Please Please Please......... help me regarding this matter if somebody knows about car audio installation.
 |
|
|
1
|
OttoFalcon |
42 |
9th August 2009 - 10:19 PM Last post by: SRSONE |
I Have a 1991 Montero US 4 door and recently i started having problems with my radio, power locks, clock, dome lights and door ajar light not working, they work sometimes, but then they go off, it's very anoying and kind of scary because I've put about $2400 in this montero and It will suck if it catches fire!
so if anybody knows of anything that might cause this kind of problem i'd really apreciate it!
Thanks!!
 |
|
|
2
|
lindyd |
51 |
7th August 2009 - 05:28 AM Last post by: Emka |
Hi all
I am a total newbie, and totally ignorant please help!
My husband and I (it's his car really but he doesn't use the computer) purchased a Mitsubushi Space Wagon 7 seater Friday from a local dealer for £995 (reputable main road one not a back street one).
When we went to view it he mentioned it had an immobiliser (we have never had a car with an immobiliser before as our previous cars have all one very old ones) and had no idea how they worked. He said to get the car to start we needed to put the ignition key in turn it on (nothing happens) and then take it out and then lock and unlock the car doors..and re insert the ignition key..he did this on 3 separate occasions and and the car started ok so we had no reason to doubt that this was the way to deactivate the immobiliser (remember we have never had an immobiliser before!)
We paid for the car and took it home yesterday. when we parked up at the supermarket and returned to start the car we did as he had said and nothing happened. We had to play around locking and unlocking the doors a number of times to get the car to start.
This then happened a few times each time we stopped and needed to restart the car. Very frustrating...
I rang the dealer when I got home and he said that there was not a problems as "it had worked everytime he had done it"
I then researched on the internet and found that the car should start just with the key which sends a signal to the car and the locking and unlocking is not a part of the procedure..there is obviously a fault with the key or car!
I rang our local Mitsubushi dealer and the technician was not there and I was told to ring back Monday. However the person who answered said that it should be possible to obtain a new key although it would be quite expensive and we would have to book the car in.
We have used it again today and have managed to get it to start evenutally each time doing the unlocking and unlocking thing but there seems to be no consistancy how many times we have to do it!
Has anyone any thoughts or comments on this please?
Thanks Lindy xx
 |
|
|
0
|
hrdavis3 |
80 |
5th August 2009 - 09:12 PM Last post by: hrdavis3 |
I recenty bought the metra harness to put an aftermarket deck with the stock infinity system. After a couple "Y" connectors and many screws later, i got it working. it sounded fine for a couple of days....then i think it all shorted out (bad ground probably) and now i hear nothing. i have been stumbling around on the net trying to find some info...but so far i have found NOTHING!!!
i need to know
1. What is the model # for the stock infinity amp mounted under the rear deck. i removed it and there are absolutely no markings of any kind
2. If it is worth buying a new one and installing it, since it did sound decent before the short.
3. If ANY one knows the speaker wire colors (minus the rear speakers since the wires are exposed)
any info on this would be a big help.
[attachment=11240:WIRING.jpg]
 |
|
|
0
|
JFossTheBoss |
26 |
5th August 2009 - 03:11 AM Last post by: JFossTheBoss |
Hey,
I just ordered the DNX-5120, and was wondering how to bypass the video safety feature, so that videos can play while driving.
Yes, I do know this model is discontinued, but I got it for less than $400 so it is worth it.
I'm asking because I have a zune, so the only way for the song titles to appear on the screen is to use the zune a/v pack. Microsoft Zunes are not compatible with anything. Haha, and no, I'm not going to be trying to watch DVDs while driving.
I read that you have to ground the parking brake wire or splice it with the radio wire which is already grounded. What does this mean and how do I do it? I would like to install it myself to save the extra money, but if it is really difficult, then I will just have to pay to have it done.
And just wondering, does anybody have this headunit? Do you like it?
Thanks,
Joe
 |
|
|
2
|
ccs84 |
75 |
4th August 2009 - 07:09 PM Last post by: ccs84 |
I have checked all fuse and they seem ok. All together the things that have stopped working, the door's no longer lock when you start driving but when you turn the ignition off it sound's like it's unlocking, when you have got the headlights on and open the driver's door the buzzer don't go off to tell you your lights are on, when you start the car the heaters come on the same setting every time, the light on the mirror stopped working, the clock on the dash don't work no more. I have now wired the stereo straight from the battery so at least that is working.....
 |
|
|
0
|
camphotos |
78 |
2nd August 2009 - 10:48 PM Last post by: camphotos |
Can anyone help me find the tv tuner for my Mitsubishi 8g vrg Galant my car has the navigation system but the tv tuner is not with it, the jacks are there, i tried one of my friends tuner from his 8g and it worked so i'm looking for the tuner for my 8g.
 |
 |
|
0
|
MTSgalant_422 |
22 |
21st July 2009 - 06:25 PM Last post by: MTSgalant_422 |
Hey!
i wanted to add an oil pressure gauge to my gauge pod, i know my car comes with a dummy light on the dash and was wondering if it was even possible to wire an oil pressue gauge instead of having my light come on at lower pressure. i have a 99 galant ES 4 CYL Thank you!
 |
|
|
1
|
mturker |
1,251 |
19th July 2009 - 03:24 PM Last post by: Starsky |
I have a 9138 (RX-1E94WT-WS no display) on a Mitsubishi Carisma (2001)
The picture is here:
http://codedradio.info/pics/MITSUBISHI/9181.jpgIt is CD Changer aware system and it has a CD Changer jack.
The picture is here :
http://www.erta.ru/base/mitsubishi/9181.shtmlI dont know Russian but it says this is a CD Changer thing according to babylon

So, how to check if an aftermarket CD Changer fits to my radio/casette player ? Is this a Pioneer system actually or an Alpine ?
The page says ALPINE Chm-S630 or Cha-S634 fits , is it true ? Can I order without checking ?
Thanks
 |
|
|
7
|
RazorAce |
151 |
17th July 2009 - 08:52 PM Last post by: JFossTheBoss |
I just bought white glow gauges for my 99 Eclipse and i was wondering what all i needed to know, and how i would go about installing them. Thanks.
 |
|
|
5
|
RazorAce |
137 |
17th July 2009 - 11:12 AM Last post by: RazorAce |
Hey, my radio was working fine, but after i went and took my underglow off, i think i might have pulled a wire or something? I took the radio out to see if it was getting power and the "power" wire does, but the "ignition" does not. Any ideas? I was thinking maybe a fuse but idk. I looked for a pulled wire in my harness but i didnt see anything.
Thanks.
|
|
|
